Extech AN300-C: Airflow Cone and Funnel Adapter Kit for AN300, AN310, AN320

 Download

             00961 1 894 243

$360.00

Description

Accessory Kit for Airflow Measurements for Common Large Size Ducts

Model AN300-C
Air Flow Adaptor Kit

INTRODUCTION:
The AN300-C Cone Adaptor Kit is intended for use with the Extech AN300 series Anemometers only (AN300, AN310, and AN320). The AN300-C kit includes a round and a square adaptor.

OPERATION:
1. Attach the round or the square adaptor to the AN300 series meter. Ensure that the adaptor is well mounted and locked before continuing
2. The meter will automatically recognize the adaptor (the adaptor icon will appear).
3. The meter’s AREA setting will now default to the dimensions of the vane opening.
4. Connect the adaptor to the air duct or vent and measure Air Volume as described in the AN300 series user manual.

DIMENSIONS:
Round Adaptor area dimensions: 210mm (8.3”) diameter Square Adaptor area dimensions: 346 x 346mm (13.6“x 13.6”) Material: ABS plastic
