Description
Features:
- Test Voltages of 250V, 500V, and 1000V
- Measure Insulation Resistance to 5.5GOhm (autoranging)
- AC Voltage measurement from 30 to 600V
- Polarization Index measurement (PI)
- Dielectric Absorption Ratio measurement (DAR)
- 10MOhm internal resistance test
- Low Resistance measurement with Zero function
- Continuity beeper
- Large 2000 count dual display with backlight
- High voltage and overload indication
- Auto-discharge and voltage output warning functions
- Low battery indication
- Complete with test leads, alligator clips, 6 AA batteries, hard cover, and soft carrying case
| Specifications | Range | Basic Accuracy |
|---|---|---|
| Test Voltage | 250V/500V/1000V | |
| Insulation Resistance (autoranging) | 0.00 to 99.9MΩ , 100M to 5.5GΩ | ±5% of reading |
| AC Voltage | 30 to 600V | ±2% of reading |
| Resistance | 0.00 to 200Ω | ±2% of reading |
| Dimensions | 6 x 4 x 2.8″ (150 x 100 x 71mm) | |
| Weight | 1.5lbs (0.7kg) | |
