Description
Lutron GC-2028 Carbon dioxide Monitor is a budgetary monitor making it simple to take fast and accurate readings of CO2 levels and Temperature. It is one of the best and most accurate device to measure concentration of carbon dioxide and temperature in atmosphere.
Application: HVAC, Nursery, Landfill gas, Ventilation administration, Mining, basement and gas stores, Transport, Railroad/air terminal holding up corridors, Schools, Library, Trains, Healing facilities, Office etc.
Features Of Lutron Carbon Dioxide Meter:
- NDIR technique foremost for CO2 ( Carbon dioxide ) estimation, accessible for long haul activity.
- High repeatability and high exactness.
- Separate test, simple task and advantageous for remote estimation.
- CO2 work with alert setting
- Large LCD, high complexity, simple readout.
- Data hold to freeze the values
- Records Maximum and Minimum readings with Recall.
- Microprocessor circuit guarantees greatest conceivable exactness, gives unique capacities and highlights.
- Heavy obligation and minimized lodging with hard conveying case, designed for simple use.
- Heavy duty & compact housing with hard carrying case,designed for easy carry out & operation
- Auto shut off is available to save battery life
- Power supply from batteries or DC 9V adapter
Additional Information
| Manufacturer | Lutron |
|---|---|
| Model No | GC-2028 |
| Measuring Parameters | Carbon Dioxide, Temperature |
| Carbon Dioxide | 0 to 4,000 ppm |
| Resolution_1 | 1 ppm |
| Accuracy_1 | +- 40 ppm for <=1,000 ppm: +- 5% of reading for > 1,000 ppm <=3,000 ppm: +- 250 ppm typically for > 3,000 ppm, reference only |
| Temperature | 0 to 50°C |
| Resolution_2 | 0.1°C |
| Accuracy_2 | 0.8 ℃ |
| Display | LCD size: 52 mm x 38 mm dual function LCD display |
| Operating Temperature | 0 to 50°C |
| Operating Humidity | <80% RH |
| Response Time | <2min Typically |
| Relay/ Alarm | Alarm For CO2 measurement only. |
| Repeatability | CO2: +- 20 ppm for <=3,000 ppm |
| Power Supply | DC 1.5 V battery (UM3,AA) x6 pcs, or equivalent. |
| Options Available | Data Logging consista of USB cable/Data Acquisition Software,SW-U801-WIN |
| Dimension | 173 x 68 x 42 mm (7.9 x 2.7 x 1.2 inch) |
| Weight | 500 Grams |
